The UNI-T UT204+ Digital Clamp Meter is a reliable and versatile measuring instrument designed for professional and industrial use. It accurately measures AC/DC current up to 600A, high voltage, frequency, and temperature, making it suitable for a wide range of electrical applications. The meter features a clear LCD backlight display with a 6000-count resolution, ensuring easy reading even in low-light conditions. Designed for user convenience, it includes an auto power-off function to save battery life and enhance safety. Durable and easy to operate, the UNI-T UT204+ is ideal for electricians, technicians, and maintenance professionals.
Specifications – UNI-T UT204+ Digital Clamp Meter
Brand: Uni-T
Model: UT204+
AC Current: 600A
DC Current: 600A
AC Voltage: 600V
DC Voltage: 600V
AC Voltage Frequency: 10Hz – 60kHz
Frequency: 10Hz – 10MHz
Resistance: 60MΩ
Capacitance: 60mF
Temperature: -40°C to 1000°C
Auto Range
True RMS
Non-Contact Voltage (NCV) Test
Live Wire Test
Continuity & Diode Test
MAX / MIN Measurement
Relative Mode
ZERO Mode
Data Hold
Low Battery Indication
Auto Power Off
Power Supply: 1.5V (R03) Battery × 2
Display Size: 37mm × 25mm
Product Color: Red & Grey
Net Weight: 235g
Product Dimensions: 215mm × 63mm × 36mm
